Description
All of our complete Bikes are dispatched flatpacked with some assembly required. For the product warranty to be valid, the bike must be assembled by a qualified cycle mechanic. If you wish to collect your bike in-store it will come fully built and ready to ride, completely free of charge!
| GEOMETRY | |
|---|---|
| (A) TOP TUBE LENGTH | 561mm |
| (B) CHAINSTAY LENGTH | 385mm |
| (C) HEAD ANGLE | 69° |
| (E) SEAT TUBE ANGLE | 70.5° |
| (F) STANDOVER | 710mm |
| (G) REACH | 400mm |
| (H) STACK HEIGHT | 563mm |
| (J) FORK OFFSET | 41mm |
| SPECS | |
| FRAME | Blackjack Pro |
| FORKS | Manitu Circus Comp 100mm |
| HANDLEBARS | Mafia Pro Jump 1 W762mm X H62mm |
| GRIPS | Mafiabikes Lucky 6 150mm |
| HEADSET | 1 1/8” -1.5″ Tapered – Integrated – Sealed bearings |
| STEM | Forged Frontload – Ø31.8 |
| PEDALS | 9/16” Mafiabikes plastic |
| SADDLE | Mafiabikes 1 Piece mid integrated alloy post – Ø25.4 |
| SEATPOST | Ø25.4mm integrated with seat |
| SEAT CLAMP | Ø35mm External |
| CRANKS | 170mm 4130 chromoly heat treated 19mm 8 spline 3 piece cranks |
| CHAINRING/SPROCKET FRONT | 25t Mafiabikes Steel Sprocket |
| SPROCKET/CASSETTE REAR | 10t Fully sealed Cassette |
| TYRE FRONT | Kenda Small Block Eight 26″ x 2.35″ |
| TYRE REAR | Kenda Small Block Eight 26″ x 2.1″ |
| FRONT HUB | 20mm x 110mm, sealed bearings, Disc |
| REAR HUB | Alloy shell, 3/8″ axle, Fully sealed bearings, Disc |
| RIM REAR | 26″ Double wall alloy 32h |
| RIM FRONT | 26″ Double wall alloy 32h |
| BRAKE FRONT | Mechanical disc brake 160mm rotor (supplied in roadkit) |
| BRAKE REAR | Zoom – hydraulic disc brake 160mm rotor |
| TECH | |
| WEIGHT (LBS) | 30.200000 |
| FRAME WEIGHT | 2.0Kg |
| BB TYPE | 73mm ISO Euro (19mm) |
| HEADSET TYPE | 1 1/8” -1.5″ tapered integrated |
| MAX TYRE WIDTH REAR | 66mm / 2.6″ |
| SEATPOST/SEATCLAMP | Ø25.4mm post with Ø31.8 shim, Ø35 seatclamp |
| FRONT AXLE/HUB SPACING | 20 x 110 Thru axle |
| FRAME CONSTRUCTION AND DETAILS | 6061 T6 Alloy .Forged dropouts .Integrated chain tensioners .CNC headtube .IS Disk mount .Bespoke Hydroformed tubes .ISO Threaded BB |
| ROAD KIT | Included |
| FORK CONSTRUCTION | Straight steerer |
